4%Επεξεργαστής Intel i5-13400 4.6GHz 10 cores 16 threads LGA1700 Tray
CPU Specifications
- Total
Cores 10
- # of Performance-cores 6
- # of Efficient-cores 4
- Total
Threads 16
- Max Turbo
Frequency 4.60 GHz
- Performance-core Max
Turbo Frequency 4.60 GHz
- Efficient-core Max
Turbo Frequency 3.30 GHz
- Performance-core Base Frequency 2.50 GHz
- Efficient-core Base Frequency 1.80 GHz
- Cache
20 MB Intel® Smart Cache
- Total L2 Cache 9.5 MB
- Processor Base
Power 65 W
- Maximum Turbo
Power 148
W
Supplemental Information
- Marketing Status Launched
- Launch
Date Q1'23
- Embedded Options
Available Yes
- Datasheet View now
Memory Specifications
- Max Memory Size (dependent on
memory type) 192
GB
- Memory
Types Up to
DDR5 4800 MT/s
Up to DDR4 3200 MT/s - Max # of Memory
Channels 2
- Max Memory
Bandwidth 76.8 GB/s
GPU Specifications
- GPU
Name‡
Intel® UHD Graphics
730
- Graphics Base
Frequency 300
MHz
- Graphics Max Dynamic
Frequency 1.55 GHz
- Graphics
Output eDP
1.4b, DP 1.4a, HDMI 2.1
- Execution
Units 24
- Max
Resolution (HDMI)‡ 4096 x 2160 @ 60Hz
- Max Resolution
(DP)‡ 7680 x 4320 @ 60Hz
- Max
Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
- DirectX*
Support 12
- OpenGL*
Support 4.5
- OpenCL*
Support 3.0
- Multi-Format
Codec Engines 1
- Intel® Quick Sync
Video Yes
- Intel® Clear Video HD
Technology Yes
- # of Displays Supported ‡ 4
- Device ID 0x4682/0xA782
Expansion Options
- Direct Media Interface (DMI) Revision 4.0
- Max # of DMI Lanes 8
- Scalability 1S Only
- PCI Express
Revision 5.0 and 4.0
- PCI Express
Configurations ‡
Up to 1x16+4, 2x8+4
- Max # of PCI
Express Lanes 20
Package Specifications
- Sockets
Supported FCLGA1700
- Max CPU Configuration 1
- Thermal
Solution Specification PCG 2020C
- TJUNCTION 100°C
- Package Size 45.0 mm x 37.5 mm
Advanced Technologies
- Intel® Gaussian & Neural Accelerator
3.0
- Intel® Thread
Director Yes
- Intel® Deep
Learning Boost (Intel® DL Boost) on CPU Yes
- Intel® Speed
Shift Technology Yes
- Intel® Turbo
Boost Max Technology 3.0 ‡ No
- Intel® Turbo Boost
Technology ‡
2.0
- Intel® Hyper-Threading
Technology ‡
Yes
- Intel® 64 ‡ Yes
- Instruction
Set 64-bit
- Instruction
Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel®
AVX2
- Idle
States Yes
- Enhanced Intel
SpeedStep® Technology Yes
- Thermal
Monitoring Technologies Yes
- Intel®
Volume Management Device (VMD) Yes
Security & Reliability
- Intel® Standard
Manageability (ISM) ‡ Yes
- Intel® Control-Flow Enforcement Technology
Yes
- Intel® AES New
Instructions Yes
- Secure
Key Yes
- Intel® OS Guard Yes
- Execute Disable Bit
‡ Yes
- Intel® Boot Guard Yes
- Mode-based Execute Control (MBEC) Yes
- Intel® Virtualization Technology
(VT-x) ‡
Yes
- Intel® Virtualization Technology
for Directed I/O (VT-d) ‡ Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
